Hertz Mille Pro MPK 163.3 3 Way Car Audio Speaker System

The three way MPK 163.3 car audio speakers system is dedicated to those who want the best: the MP 70.3 midrange featuring Neodymium double magnet inside the coil produces an enthralling mid range, perfect to combine with the powerful mid-low of the MP 165.3 woofer as well as with the detailed high range of the MP25.3 tweeter. The 20 mm coil of the MP 70.3 maximizes the dynamics; the V-cone® profile enhances off-axis dispersion and the Boundary Free Surround allows for a wider extension towards the low frequency range. The dedicated MPCX 3.3 crossover provides optimized crossover points to exploit the midrange remarkable extension using ultra-selected components.

V Cone Technologies

Boundary Free Surround

Component:

System

Size mm (in.):

165 (6.5)

Power Handling – Continuous W:

150

Power Handling – Peak W:

300

Impedance Ohm:

4

Tweeter diaphragm mm (in.):

29 (1.14)

Woofer Voice Coil Ø mm (in.):

25 (1)

Tweeter Voice Coil Ø mm (in.):

25 (1)

Sensitivity dB SPL:

92

Frequency Response Hz:

40 ÷ 22,5k

Crossover Cut off:

450Hz – 5.5k Hz

Crossover Type:

3 Way Passive Crossover

Adjustment:

Tweeter level 0 / +2 dB

Midrange level 0 / +2 dB

Weight of one component – Woofer:

1.07 (2.36)

Weight of one component – Tweeter kg (lb):

0.07 (0.15)

Weight of one component – Crossover kg (lb):

0.43 (0.95)
